1630-laser cutter

Product Detail

1630-laser cutter

Applicable  Materials:



wood, bamboo, jade, marble, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic,



glass and other nonmetal materials.



Applicable industries:



advertisement, arts and crafts, leather, toys, garments, model, building upholstery, computerized



embroidery and clipping, packaging and paper industry.



Feature:



Co2  laser as an energy source, combined with electronic, mechanical, computer technology



developed. Laser head and the workpiece does not contact, do not scratch the surface, the kerf, high



precision, is the ideal choice for a variety of processing industries.



Technical Parameter:



Laser type

Sealed CO2 laser tube

Laser power

60W,80W,100W,130W,150W,200W (optional)

Engraving area

900×600mm,1200×900mm,1300×900mm,1600×1000mm  and small or big for your choose

Engraving speed

0-60000mm/min

Resetting position accuracy

±0.05mm

Working voltage

AC110-220V ±10%.50-60HZ

Power

<1,000W

Operating temperature

0-45°C

Operating humidity

5-95%

Minimum shaping character

English 1×1mm

Graphic format supported

BMP, PLT,DST, DXF,and AI

Driving system

Stepper

Cooling mode

Water-cooling and protection system or choose industry chiller cw3000 cw5000 cw5200

Auxiliary equipment

Exhaust-fan, air-exhaust pipe

Controlling software

DSP control system

Compatible software

Coreldraw auto CAD photoshop



We have many different working size, such as 300*200mm,400*300mm,600*400mm 900*600mm, 1200*900mm, 1300*900mm,1400*900mm, 1300*2500mm, 1600*1200mm. or we can manufacture customer requirements.





Samples:
